IFM O2V 100 Series Vision Sensor
— ifm’s O2V series efector dualis pixel vision sensors are suitable for a wide range of inspection and error-proofing applications in manufacturing processes.
IFM O2V 100 Series Vision Sensor
Technical Features
Products + Accessories Selection:
8-pin • M12 connector
| Type | Maximum field of view [mm] | Light source type LED | Detection frequency [Hz] | Motion speed (max) [m/s] | Process interface | Transistor output (max 5 channels) | Order No. |
|---|---|---|---|---|---|---|---|
 | 400 x 300 | White light | 20 | 1 | Ethernet TCP / Ethernet IP | PNP | O2V104 |
| 400 x 300 | White light | 20 | 1 | Ethernet TCP / Ethernet IP | NPN | O2V105 | |
| 400 x 300 | Infrared light | 20 | 1 | Ethernet TCP / Ethernet IP | PNP | O2V124 | |
| 400 x 300 | Infrared light | 20 | 1 | Ethernet TCP / Ethernet IP | NPN | O2V125 | |
| 640 x 480 | White light | 20 | 1 | Ethernet TCP / Ethernet IP | PNP | O2V100 | |
| 640 x 480 | White light | 20 | 1 | Ethernet TCP / Ethernet IP | NPN | O2V101 | |
| 640 x 480 | Infrared light | 20 | 1 | Ethernet TCP / Ethernet IP | PNP | O2V120 | |
| 640 x 480 | Infrared light | 20 | 1 | Ethernet TCP / Ethernet IP | NPN | O2V121 | |
| 1320 x 945 | White light | 20 | 1 | Ethernet TCP / Ethernet IP | PNP | O2V102 | |
| 1320 x 945 | White light | 20 | 1 | Ethernet TCP / Ethernet IP | NPN | O2V103 | |
| 1320 x 945 | Infrared light | 20 | 1 | Ethernet TCP / Ethernet IP | PNP | O2V122 | |
| 1320 x 945 | Infrared light | 20 | 1 | Ethernet TCP / Ethernet IP | NPN | O2V123 |
Optional Accessories
| Type | Description | Order No. |
|---|---|---|
 | Mounting kit, 100 mm mounting rod | U60042 |
| Mounting kit, 100 mm mounting rod, with guide rail mounting block | U60043 | |
 | Plastic protective cover | E21166 |
| Plastic lens for diffuse reflector light source | E21165 | |
| Glass protective cover | E21168 | |
 | Ethernet cable, 2 m, M12 D-coded/RJ45, crossover cable | E1898 |
| Ethernet cable, 5 m, M12 D-coded/RJ45, crossover cable | E18422 | |
| Ethernet cable, 10 m, M12 D-coded/RJ45, crossover cable | E18423 |
Mating cables
| Type | Description | Order No. |
|---|---|---|
 | M12 Micro DC (8-pin) 2 m, PUR | E11950 |
| M12 Micro DC (8-pin) 5 m, PUR | E11807 | |
| M12 Micro DC (8-pin) 10 m, PUR | E11311 | |
 | M12 Micro DC (8-pin) 2 m, PUR | E11231 |
| M12 Micro DC (8-pin) 5 m, PUR | E11232 | |
| M12 Micro DC (8-pin) 10 m, PUR | E11806 |
Specifications:
- Max. load current: 100 mA (per switching output)
- Supply current: < 300 mA
- Detection frequency: 20 Hz
- Max. motion speed: 1 m/s
- Illumination: Infrared light source 850 nm
- Operating voltage: 24 VDC ± 10 %
- Operating temperature: -10…60 °C
- Protection class: IP67
- Material:
- Housing: Die-cast zinc
- Front panel: Glass
- LED window: Polycarbonate
- Trigger mode: External 24 V, PNP, NPN, continuous, TCP/IP
- Parameter setting/Process interface: Ethernet 10 Base-T, Ethernet TCP, Ethernet IP
What’s More:
Other application examples
The goal is to differentiate between black seat frames and silver seat frames. A standard mark sensor can handle this application, but usually does not have the required detection range to inspect the seat frame.
The pixel vision sensor can be used for simple mark applications when a larger detection range is needed, and can therefore easily detect the silver seat frame in this application.
When inserting a metal insert into a rubber mold, it is necessary to ensure that the area is smoothly covered. In this example, the insert has developed an inconsistent shape during molding.
The molding process can produce inconsistently shaped inserts. The pixel vision sensor can detect a smaller number of bright pixels to detect incorrect molding.
