IFM Tv7000 Series Temperature Sensor

Deal Score0

2025/7/4 Update

Independent housing, with integrated RTD｜DC Dual switch output, up to 150 °C
— The TV temperature sensor can perform long-term, high-precision fluid temperature measurement and is suitable for a wide range of industrial applications.

IFM Tv7000 Series Temperature Sensor

Technical Features

High protection rating integrated temperature switch, suitable for harsh environments.

Measuring range -50…150 °C.

Other features include plug-and-play replacement, real-time configuration file changes, and diagnostic feedback.

Two solutions: Continuous transmission of process values via IO-Link and 2 switch outputs.

Extremely high accuracy of ± 0.3 °C.

Products + Accessories Selection:

RTD length (mm)	Pressure rating (bar)	Process connection	Factory default PNP N.O. setpoint 1/2	Max. temperature range	Order no.
2 x PNP / NPN – NO / NC
25	400	G 1/4	60 °C / 120 °C	-50…150 °C	TV7105 ⓒ
30	300	G 1/2	60 °C / 120 °C	-50…150 °C	TV7405 ⓒ

Connecting Cables

Type	Description	Order No.
	M12 Micro DC (4-pin) 2 m, PUR	EVC001
M12 Micro DC (4-pin) 5 m, PUR	EVC002
M12 Micro DC (4-pin) 10 m, PUR	EVC003
	M12 Micro DC (4-pin) 2 m, PUR	EVC004
M12 Micro DC (4-pin) 5 m, PUR	EVC005
M12 Micro DC (4-pin) 10 m, PUR	EVC006

Optional Accessories

Type	Description	Order No.
	LineRecorder Device, parameter setting software (requires E30390 cable)	QA0011
	USB IO-Link master cable, for parameter setting	E30390
	Memory plug for storing sensor parameters, for easy upload without a computer	E30398

Specifications:

Measuring element: Pt1000, class A
Power supply voltage: 18…32 VDC
Maximum load current: < 100 mA
Switch point accuracy: ± 0.3 °C
Response time T05 / T09: 1/3 sec
Ambient temperature: -25…80 °C
Wetted parts: 316L stainless steel
Protection class: IP69K

Benefits Introduce In Detail

Two temperature sensors in one

The TV temperature sensor can perform long-term, high-precision fluid temperature measurement and is suitable for a wide range of industrial applications. The one-piece housing with integrated electronics, 6 mm diameter probe, and threaded process connection are made of durable 316 stainless steel to withstand harsh environments. Due to its compact external shape, it is very suitable for installation in tight application spaces.

Fast and Accurate

The ifm TV temperature sensor uses a high-precision Pt1000 class A RTD and a lightweight, fast-responding probe head.

The sensor has 2 switch points that can be easily set via Line Recorder device software. The TV sensor uses dual switching outputs or IO-Link connected to a PLC to integrate into any control system.

Reliable Digital Transmission via IO-Link

IO-Link provides pure digital transmission, which is more accurate than analog signal output. By using IO-Link, the TV temperature sensor can send minimum and maximum temperature values to the controller. By continuously analyzing real-time process data, the machine can maintain high precision and the operator can better utilize the full efficiency of the equipment.
